Processor
32-bit Secure Processor
Image Sensor
CMOS, 30fps
640 (H)× 480 (V)
Field of View Angle
Horizontal 31°, Vertical 24°
Barcode Sensitivity
Rotary 360°
Inclined ±55°
Deflected ±55°
Reading Depth of Field
EAN13 (13mil): 40~200mm
Code128 (20mil): 45~250mm
Code39 (5mil): 45~95mm
Peripheral Ports
USB Virtual Serial Port, Serial Port, HID-KBW (Default)
Dimensions
92×64×168mm
L×W×H
Weight
172g
Power Supply
Operating Voltage: 5V
Operating Current: 125mA
Line length
1.8 meter
Symbol Contrast
≧20%
Resolution
1D ≧5mil
2D ≧10mil
Motion Tolerance
35cm/s
Symbologies
Default Enabled (1D): EAN13, EAN8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar
Default Close (1D): Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSI Plessey, RSS-14, RSS-Limited, RSS-Expand，Standard 2 of 5, Plessey, ChinaPost 25
Default Enabled (2D): QR Code, PDF417, DataMatrix (ECC200), Micro QR
Default Close (2D): Micro PDF417, Code 16K, Maxi Code, Aztec
Environmental
Operating Temperature:
-20℃ ~ 60℃
Storage Temperature:
-40℃ ~ 70℃
Relative Humidity:
5% ~ 95%, Non-condensing
