Technical Specifications

•

  OS

  RTOS

•

  Processor

  Dual-core Cortex-A5, 500MHz+Secure Processor

•

  Memory

  RAM: 16MB

  FLASH: 8MB

•

  Card Slots

  1 * SIM

•

  Peripheral Ports

  1 * Micro USB

•

  Speaker

  4Ω3W, Adjustable Volume

•

  Dimensions

  111.5×117×155mm

  L×W×H

•

  Weight

  328g

•

  Indicator Lights

  1 * Power Indicator

  1 * Status Indicator

•

  Battery

  3.7V/2000mAh

•

  Power Supply

  Input: 100V-240V 50/60Hz

  Output: 5V/1A

•

  Accessory

  Power Adapter (Optional)

  USB Cable

•

  Display

  Main Screen:

  1.65" LED Display

  Customer Screen:

  2.8" Color Screen, 320×240 Pixels

  2.4" Color Screen, 320×240 Pixels (Optional)

•

  Card Reader (Optional)

  Contactless Card Reader

•

  Keys

  12 * Alphanumeric Keys

  6 * Function Keys

  1 * Power Key

  1 * Reset

•

  GNSS (Optional)

  GPS/GLONASS/BeiDou

•

  Communication

  4G Cat1+2G

  Optional:

  4G Cat1

  Wi-Fi 2.4GHz

•

  Environmental

  Operating Temperature:

  -10℃～50℃

  Storage Temperature:

  -20℃～70℃

  Relative Humidity:

  5%～95%, Non-condensing

•

  Certifications

  PCI PTS 6.x, EMV CL L1, Mastercard Paypass, Visa Paywave, JCB J/Speedy, Amex Expresspay, Discover D-PAS, RuPay, Mastercard TQM, CE, BIS, WPC
