Technical Specifications

•

  Processor

  32-bit Secure Processor

•

  Image Sensor

  CMOS, 30fps

  640 (H)×480 (V)

•

  Field of View Angle

  Horizontal 47°, Vertical 35°

•

  Barcode Sensitivity

  Rotary 360°

  Inclined ±45°

  Deflected ±45°

•

  Audio

  Speaker

•

  Peripheral Ports

  1 * USB Type-A

•

  Dimensions

  90×90×100mm

  L×W×H

•

  Weight

  195g

•

  Cable length

  1.5 meter

•

  Symbol Contrast

  ≧20%

•

  Motion Tolerance

  45cm/s

•

  Resolution

  1D ≧5mil

  2D ≧10mil

•

  Symbologies

  Default Enabled (1D): EAN13, EAN8, UPC-A, UPC-E0, UPC-E1, Code128, Code39

  Default Close (1D): Code93, CodaBar，Interleaved 2 of 5

  Default Enabled (2D): QR Code

  Default Close (2D): PDF417, DataMatrix

•

  Reading Depth of Field

  EAN13 (13mil): 0~110mm

  Code128 (20mil): 0~150mm

  Code39 (5mil): 0~30mm

  Wechat Payment Code

  (5" Screen): 0~250mm

•

  Environmental

  Operating Temperature:

  -20℃ ~ 55℃

  Storage Temperature:

  -40℃ ~ 70℃

  Relative Humidity:

  5%~95%, Non-condensing

•

  Power Supply

  Operating Voltage: 5V

  Operating Current: 150mA
