OS
VanLin
Processor
Cortex-A5, 500MHz+Secure Processor
Memory
RAM: 16MB
FLASH: 24MB
Display
2.8" Color Display, 320×240 Pixels
Optional: Capacitive Touchscreen
Card Readers
Magstripe Card Reader
Smart Card Reader
Contactless Card Reader
Printer
Thermal Printer
Paper Width: 58mm
Diameter: 40mm
Keys
10 * Alphanumeric Keys
9 * Function Keys
Backlit (Optional)
Indicator Lights
1 * Power Indicator
Audio
Buzzer
Speaker (Optional)
Battery
Portable Version:
3.6V/2600mAh
Camera (Optional)
0.3MP Front Camera, 1D/2D Scanning
Accessory
Portable Version:
Power Adapter
USB Cable
Countertop Version:
Power Adapter
Communication
Portable Version:
4G (Supports 2G)
Optional：
Wi-Fi 2.4GHz & Bluetooth 5.0
Countertop Version:
4G (Supports 2G)
Optional：
Wi-Fi 2.4GHz & Bluetooth 5.0
Card Slots
Portable Version:
1 * SIM & 2 * SAM
Optional:
2 * SIM & 1 * SAM
Countertop Version:
2 * SAM
1 * SIM
Environmental
Operating Temperature: 0℃~50℃
Storage Temperature: -20℃~70℃
Relative Humidity:
5%~95%, Non-condensing
Peripheral Ports
Portable Version:
1 * Powered USB Type-C
Countertop Version:
1 * Powered USB Type-C
1 * DC for Charging
1 * RS232 Port
1 * Ethernet Port
1 * Modem (Optional)
Power Supply
Portable Version:
Input: 100V-240V 50/60Hz
Output: 5V/2A
Countertop Version:
Input: 100V-240V 50/60Hz
Output: 9V/2A
Certifications
PCI PTS 6.x, EMV L1&L2, EMV CL L1, Mastercard Paypass, Visa Paywave, JCB J/Speedy, Amex Expresspay, Discover D-PAS, UnionPay QuickPass, Mastercard TQM, ROHS, FCC, CE
