Click to view
OS
VanDroid
Based on Android 10.0
Processor
Quad-core Cortex-A53, 1.4GHz+Secure Processor
Memory
RAM: 1GB (Optional 2GB)
FLASH: 8GB (Optional 16GB)
Display
5" IPS Display, 1280×720 Pixels
Multi-point Capacitive Touchscreen
Camera
0.3MP Bottom Camera
1D/2D Scanning
Card Readers
Smart Card Reader
Contactless Card Reader
Audio
Speaker
Card Slots
1 * SIM
4 * PSAM
Keys
1 * Reset key
Communication
4G (Supports 3G&2G)
Bluetooth 5.0
Wi-Fi 2.4GHz (Optional 5GHz)
Peripheral Ports
2 * RS232
1 * USB Type-A
1 * USB Type-C
1 * Ethernet Port
1 * MDB Slave
1 * Digital I/Os
1 * MDB Master
1 * SMA
1 * DC
GNSS
GPS/BeiDou
GPS/GLONASS (Optional)
Dimensions
184.5×100.5×39.6mm
L×W×H
Power Supply
7V - 48V DC via MDB Slave or MDB Master or Digital I/O or DC Jack
Environmental
Operating Temperature: -20℃~70℃
Storage Temperature:-30℃~70℃
Relative Humidity: 5% - 95%, Non-condensing
Certifications
PPCI PTS 6.x, EMV L1&L2, EMV CL L1, Mastercard Paypass, Visa Paywave, JCB J/Speedy, Amex Expresspay, Discover D-PAS, UnionPay QuickPass, PURE, RuPay, MIR, VCCS, Mastercard TQM, ROHS, FCC, CE, SABER, BIS, WPC, SONCAP, IK09, IP65
