Technical Specifications

•

  OS

  RTOS

•

  Processor

  Cortex-R5, 614MHz

•

  Memory

  RAM: 4MB

  FLASH: 12MB (Optional 20MB)

•

  Indicator Lights

  1 * Status Indicator

•

  Card Slots

  1 * SIM

•

  Speaker

  4Ω5W, Adjustable Volume

•

  Battery

  3.7V/2000mAh

•

  Accessory

  Power Adapter (Optional)

  Type-C Cable

•

  Camera (Optional)

  0.08 MP Front Camera

  1D/2D Scanning

•

  Communication

  4G Cat1

  Wi-Fi 2.4GHz (Optional)

•

  Power Supply

  Input: 100V-240V 50/60Hz

  Output: 5V/1A

•

  Certifications

  ROHS, CE, BIS, WPC

•

  Card Readers (Optional)

  Contactless Card Reader

•

  Peripheral Ports

  1* USB Type-C for Charging

•

  Environmental

  Operating Temperature: -10℃~45℃

  Storage Temperature: -20℃~70℃

  Relative Humidity: 5%~95%, Non-condensing

•

  Display

  Customer Screen:

  3.5" Display, 480×320 Pixels

  Main Screen:

  7-Segment Display

•

  Keys

  1 * Power Key

  1 * Function Key

  2 * Volume Up/Down Keys

  1 * Reset Pinhole

  Keypad:

  11 * Numeric Keys

  5 * Function Keys
