Technical Specifications

•

  OS

  RTOS

•

  Processor

  Dual-core Cortex-A5, 500MHz+Secure Processor

•

  Memory

  RAM: 16MB

  FLASH: 8MB

•

  Card Slots

  1 * SIM

  1 * SAM

•

  Peripheral Ports

  1 * USB Type-C for Charging

•

  Speaker

  4Ω2W, Adjustable Volume

•

  Dimensions

  142×130×95mm

  L×W×H

•

  Weight

  326g

•

  Indicator Lights

  1 * Power Indicator

  1 * Status Indicator

•

  Battery

  3.7V/2000mAh

  Removable

•

  Power Supply

  Input: 100V-240V 50/60Hz

  Output: 5V/1A

•

  Accessory

  Power Adapter (Optional)

  USB Cable

•

  Card Reader

  Contactless Card Reader

  Smart Card Reader

•

  GNSS (Optional)

  GPS/GLONASS/BeiDou

•

  Camera (Optional)

  0.3MP Front Camera

  1D/2D Scanning

•

  Communication

  4G Cat1+2G

  Optional:

  Wi-Fi 2.4GHz

•

  Environmental

  Operating Temperature: -10℃~50℃

  Storage Temperature: -20℃~70℃

  Relative Humidity: 5%~95%, Non-condensing

•

  Keys

  10 * Alphanumeric Keys

  8 * Function Keys

  1 * Power Key

  Key Backlight (Optional)

•

  Certifications

  PCI PTS 6.x, EMV L1&L2, EMV CL L1, Mastercard Paypass, Visa Paywave, JCB J/Speedy, Amex Expresspay, Discover D-PAS, UnionPay QuickPass, RuPay, VCCS, Mastercard TQM, CE, BIS, WPC

•

  Display

  Main Screen:

  2.09" LCD Screen, 128×32 pixels

  Customer Screen:

  3.5" Color Screen, 320×480 Pixels
