OS
Linux
Processor
ARM Cortex-A7
1.2GHz+Secure Processors
Memory
RAM: 256MB
FLASH: 256MB
Micro SD Card (Optional)
Display
3.5" TFT Display, 320x480 pixels
Resistive Touchscreen (Optional)
Capacitive Screen (Optional)
Card Readers
Magstripe Card Reader
Smart Card Reader
Contactless Card Reader
Audio
Buzzer
Card Slots
2 * SIM
1 * PSAM
1 * Micro SD
Printer
Thermal Printer
Paper Width: 58mm
Diameter: 40mm
Keys
1 * Keyboard includes 15 keys
1 * Power Key
Communication
4G (Supports 3G&2G)
Optional:
Wi-Fi & Bluetooth
Peripheral Ports
1* Powered USB
Type-C, Host/Device
Dimensions
176x78x68mm
L×W×H
Weight
328g
Indicator Lights
4 * Contactless Indicators
1 * Charging Indicator
Battery
2600mAh, 3.6V
Power Supply
Input: 100V~240V AC 50/60Hz
Output: DC 5V/2A
Certifications
PCI PTS 6.x, EMV Level L1&L2
EMV CL L1, Visa Paywave, Mastercard Paypass, Mastercard TQM, JCB J/Speedy, Amex Expresspay, Discover D-PAS, UnionPay QuickPass, CE, ROHS, UN38.3
Environmental
Operating Temperature: 0℃~50℃
Relative Humidity: 10%~90%, Non-condensing
Storage Temperature: -20℃~70℃
Relative Humidity: 5%~95%, Non-condensing
Optional Configurations
Camera: 0.3MP Single Camera, 1D/2D Scanner
Fingerprint Module
Accessory
Stylus Pen (Optional)
GNSS
Optional: GPS/BDS/GLONASS/GALILEO/QZSS
