OS
Linux
Processor
Cortex-A7,
1.2GHz+Secure Processor
Memory
RAM: 256MB
FLASH: 256MB
Micro SD Card (Optional)
Display
3.5" TFT Display, 320×480 Pixels
Resistive Touchscreen (Optional)
Capacitive Screen (Optional)
Card Readers
Magstripe Card Reader
Smart Card Reader
Contactless Card Reader
Communication
4G (Supports 3G&2G)
Optional:
Wi-Fi & Bluetooth
Card Slots
2 * SIM
1 * PSAM
1 * Micro SD
Printer
Thermal Printer
Paper Width: 58mm
Diameter: 40mm
Keys
10 * Alphanumeric Keys
5 * Function Keys
Peripheral Ports
1 * Powered USB Type-C, Host/Slave
Dimensions
176×78×68mm
L×W×H
Indicator Lights
4 * Contactless Indicators
1 * Charging Indicator
Weight
328g
Audio
Buzzer
GNSS (Optional)
GPS/BDS/GLONASS/GALILEO/QZSS
Battery
3.6V/2600mAh
Camera (Optional)
0.3MP Rear Camera,
1D/2D Scanning
Power Supply
Input: 100V-240V 50/60Hz
Output: 5V/2A
Accessory
Stylus Pen (Optional)
Power Adapter
USB Cable
Optional Configurations
Fingerprint Module
Docking Stations:
Support Charging, Modem, Serial Ports, Ethernet, USB Extension Port, Wireless Communication
Environmental
Operating Temperature: 0℃~50℃
Storage Temperature: -20℃~70℃
Relative Humidity:
5%~95%, Non-condensing
Certifications
PCI PTS 6.x, EMV L1&L2, EMV CL L1, Mastercard Paypass, Visa Paywave, JCB J/Speedy, Amex Expresspay, Discover D-PAS, UnionPay QuickPass, MIR, Mastercard TQM, ROHS, FCC, CE, Anatel, SONCAP, UN38.3, ABECS
