Technical Specifications

•

  OS

  RTOS

•

  Processor

  Dual-core Cortex-A5

  500MHz

•

  Memory

  RAM: 16MB

  FLASH: 8MB

•

  Card Slots

  1 * SIM

  1 * SAM

•

  Card Readers

  Contactless Card Reader

•

  Camera

  0.3MP Camera

  1D/2D Scanning

•

  Peripheral Ports

  1 * Micro USB

  1 * RS232

•

  Indicator Lights

  4 * Contactless Indicators

  1 * Power Indicator

•

  Speaker

  8Ω1W, Adjustable Volume

•

  GNSS (Optional)

  GPS/GLONASS/BeiDou

•

  Weight

  200g

•

  Dimensions

  170×77×51 mm

  L×W×H

•

  Battery

  3.7V/2000mA

  3.7V/2600mAh (Optional)

•

  Power Supply

  Input: 100V-240V 50/60Hz

  Output: 5V/1A

•

  Accessory

  Power Adapter (Optional)

  USB Cable

•

  Keys

  12 * Alphanumeric Keys

  3 * Function Keys

  1 * Power Key

•

  Communication

  4G Cat1

  Wi-Fi 2.4GHz

  Optional:

  Bluetooth BR+BLE4.2, Dual-mode

•

  Display

  Main Screen:

  2.4" Color Screen,

  320×240 Pixels

  Electronic Signature (Optional)

  Customer Screen:

  LCD Segment Display (Optional)

•

  Environmental

  Operating Temperature:

  -10℃ ~ 50℃

  Storage Temperature:

  -20℃ ~ 70℃

  Relative Humidity:

  5%~95%, Non-condensing
